VSW250131-CA — SMA MALE STARIGHT TO SMB MALE RIGHT ANGLE FOR RG316 CABLE ASSEMBLY LENGTH OF 6INCH
- RF Cable Assembly
- SMB Cable Assembly
- SMB to SMB Cable Assembly
- RG316 Cable
Description
| SPECIFICATION | |
| RF Series 1 | SMB |
| Gender | Plug(Male) |
| Orientation1 (body) | Straight |
| Body Finish | Gold |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| RF Series 2 | SMB |
| Gender 2 | Plug(Male) |
| Orientation 2 (body) | Right Angle |
| Body Finish | Gold |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| Mounting Features | – |
| Frequency | DC to 3Ghz |
| VSWR | ≤1.2 |
| CABLE SPECIFICATION | |
| Cable Type | RG316 |
| Cable Diameter | 2.49 ±0.1 |
| Frequency | DC to 6Ghz |
| Impedance | 50Ω ±2Ω |
| Length | 6inch |
| Operating Temperature | -55°C to +200°C |
