Rubber Duck With Magnetic Mount Antenna (865-868MHz 3dBi)
P/N : VSW250121-AN
- RF Antenna
- Antenna Type : Rubber Duck Antenna
- Frequency : 865-868MHz
- Gain : 3dBi
Applications:
- European Lora WAN and Helium gateways
- Vehicle telemetry and asset tracking
- Industrial SCADA monitors
- Agricultural sensor hubs
- Smart metering collectors
 Click here to get Data Sheet
Description
| ELECTRICAL AND MECHANICAL SPECIFICATION | |
| Frequency range | 865-868MHz |
| Impedance | 50 Ω |
| Gain | 3 dBi |
| Direction | Omni 360 degree |
| Polarization | Vertical/horizontal |
| Antenna Height with Mounting |  22 cm |
| Antenna Connector                                 | SMA Male Plug |
| Magnetic Base Diameter | 2.4 inches/6 cm |
| Magnetic Base Cable Connector | SMA Male Plug |
| Coax Cable Type | RG174 Cable |
| Length | 3 meters |
| Radom | UV Protected ABS Granules |
| Operation Temp | -40C ~ +60C |
