High Gain GSM SISO Antenna (698-4200MHZ 12dBi)
P/N : VSW-GSM-SISO-12DBI
- RF Antenna
- Antenna Type : High Gain GSM SISO Antenna
- Frequency : 698-4200MHz
- Gain : 12dBi
- Connector : N Female
Applications:
- Cellular Signal Boosters
- Smart Utility & Industrial IoT
- Legacy Routers & Modems
- Vessel & Fleet Connectivity
 Click here to get Data Sheet
Description
| ELECTRICAL & MECHANICAL SPECIFICATION | |
| Freq. range(MHz) | 698-4200Mhz |
| Polarization | ±45° |
| Gain(dBi) | 10+2 |
| Electrical Down tilt(°) | 45 |
| HBW(°) | 70±10 |
| VBW(°) | 65±10 |
| Front-to-back ratio (dB) | ≥20 |
| Impedance(Ω) | 50 |
| VSWR | ≤1.8 |
| Cross polar discrimination(dB) | ≥15（±60°≥8） |
| Connector and Cable | N-type Female RG-141 |
| Connector position | Bottom |
| Antenna size(mm) | 320×286×85 |
| Packing size(mm) | 350×300×100 |
| Weight(Kg) | ≤3 |
| Radom material and colour | UPVC/Gray |
| Mechanical tilt(°) | 0-15 |
| Operating temperature(℃) | -40-60 |
| Rated wind velocity(m/s) | 60 |
| Suitable pole/wall diameter(mm) | Φ35-Φ70 |
| Isolation(dB) | ≥25 |
| Maximum power(W) | 100 |
| Ground | DC Ground |
