GPS Antenna (1575 MHz 3dBi) - Image 1

Click to enlarge

GPS Antenna (1575 MHz 3dBi)

P/N : VSW-GPS-3dBi

RF Antenna
Antenna Type : GPS Antenna
Frequency : 1575 MHz
Gain : 3dBi

Applications:

Automotive Navigation & Telematics
Marine Navigation
Industrial & Outdoor IoT Base Stations

Click here to get Data Sheet

Category: GPS Antennas Tags: 1575 MHz, 3dBi, GPS Antenna

Description
Reviews (0)

Description

SPECIFICATION
Operating Frequency	1575 MHz
LNA gain(without cable)	27dB
Gain	3dB
Operating Voltage (VDC)	3 ~ 7
Operating Current	15mA
VSWR	2:1
Impendence	50 Ω
Connector	SMA-Male
Colour	Black
Cable Size (AWG)	2.6
Weight (gm.)	60
Cable Length (Meter)	3
